ZONDA W
V-type single-row dry cooler
ZONDA is the new V-type single-row dry cooler allow heat exchange designed for limited space availability or visibility on the roofs.
ZONDA W
V-type single-row dry cooler
ZONDA is the new V-type single-row dry cooler allow heat exchange designed for limited space availability or visibility on the roofs.
0
Models in 3 configuration
0 kW
From 20 to 800 kW – DT 15K Capacity
0 kW
Up to 560 kW with only 45 dB(A) 10 m EG35% DT15K EC
0 kW/m²
Up to 1100 kW/m² DT15 EG 35% – High capacity per foot print
0 %
+ 12% increased thickness high-efficiency rippled tube
0%
+ 20% increased thickness high-efficiency louvered fins
800 kW up to 800kW in only 1.2mt height – EG35% DT15k
High nozzles
For maximum efficiency
Three possible configurations
W1,2×L1,5×H1,2
W1,2×L1,7×H1,2
W1,2×L1,2×H1,5
Solid structure
With casing and heading protections
Low noise
To reduce noise levels we offer two silencer versions
EC fan technolgy
to increase significantly silence level and energy saving
Versions with ADIABATIC operation
with non-organic PAD
Performance
Performance kW/m² of footprint
at the top of the market.
Three versions: Small, Standard, Large
for various space requirements.
Adiabatic solution
to increase performances.
Performance
Performance kW/m² of footprint
at the top of the market.
Three versions: Small, Standard, Large
for various space requirements.
Adiabatic solution
to increase performances.
Solidity
Increased thicknesses in the coil
without compromising on material quality.
Metal structure in pre-painted plate 15/10
for excellent solidity.
Connection protected
thanks to header protection pannels.
Optimised transport
with machines always sitting side by side.
